Nano-N3 Plus Industrial Mini PC with Quad Core J1900 Processor, 8GB RAM, and Fanless Design for Harsh Environments

Name: NanoN3 Plus Industrial Mini PC with Quad Core J1900 Processor 8GB RAM and Fanless Design for Harsh Environments
Brand: MTHGH
Price: 1 USD

Quality Nano-N3 Plus Industrial Mini PC with Quad Core J1900 Processor, 8GB RAM, and Fanless Design for Harsh Environments for sale

Operating Temperature : -20℃ -- +50℃

Dimensions : 134 x 126 x 38.5 mm

Processor Core : Quad Core

Rear I/O : 1xAudio,2xRJ45 LAN,1*VGA,1*HDMI,1*DC Input

Material : High-quality all aluminum,surface anodic oxidation

Display Chip : Intel HD Graphics

Storage Options : 1xMSATA，1x2.5”HDD

RAM Slot : 1*DDR3L 1333/1600MHz SODIMMRAM Slot，Max. 8 GB

Front I/O : 1xPower Switch,1xUSB3.0,5xUSB2.0,1*RS232 COM

Input Voltage : Support DC 12V Input

Display Ports : 1xVGA，1xHDMI

Processor Speed : 1.99GHz,Pulse frequency 2.42GHZ

Work Humidity : 5% ～ 95% non-condensing

Brand Name : MTHGH

Model Number : Nano-N3 Plus

Place of Origin : China

Network : 2x100/1000M RTL8111E 1000M LAN

BIOS : AMI UEFI BIOS

Processor Model : J1900

Net Weight : 0.7kg

Certification : CE,CCC,FCC Class A,ROHS

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C,T/T,Western Union

Supply Ability : 10000 Set

Delivery Time : 7-10 work days

Packaging Details : Standard carton package : carton+ plastic bag+ foam+ honeycomb paperboard+ pack thread.

USB Ports : 1*USB3.0，5*USB2.0

Contact Now

Nano-N3 Plus J1900 4 Core 8G RAM Industrial Mini PC Support OS Windows/Linux

Product Overview

The Industrial Mini PC features 1x MSATA and 1x 2.5" HDD storage options for large data storage and fast access. Equipped with 1x USB 3.0 and 5x USB 2.0 ports for connecting various peripherals. Designed with 1x VGA and 1x HDMI display ports for flexible display options to suit your application needs.

Built to withstand harsh industrial environments with reliable performance. Perfect solution for industrial applications requiring robust computing power in compact form factor.

Key Features

All aluminum structure, fanless design
Onboard Intel Celeron J1900 quad core processor
Support DDR3L Max. 8G RAM
Support 1x MSATA, 1x 2.5" HDD
Support 2*1000M LAN
Support Operating Systems:

Nano-N3 Plus Industrial Mini PC with Quad Core J1900 Processor, 8GB RAM, and Fanless Design for Harsh Environments

Technical Specifications

Model	Nano N3 Plus
Color	Black (Color can be customized)
Material	High-quality all aluminum, surface anodic oxidation
Processor	Intel Celeron J1900 (Quad core quad threading, 1.99GHz, Pulse frequency 2.42GHz)
RAM	1*DDR3L 1333/1600MHz SODIMM RAM slot, Max. 8 GB
BIOS	AMI UEFI BIOS
Display Chip	Intel HD Graphics
Display Port	1x VGA, 1x HDMI (Support synchronous and asynchronous dual display)
Front I/O	1x Power Switch, 1x USB 3.0, 5x USB 2.0, 1*RS232 COM
Rear I/O	1x Audio, 2x RJ45 LAN, 1VGA, 1HDMI, 1*DC Input
Expansion Slot	1x MINI PCIE Slot (WIFI/BT Optional) 1x MINI PCIE Slot (Support MSATA)
Network	2x 100/1000M RTL8111E 1000M LAN
Storage	1x MSATA, 1x 2.5" HDD
Input Voltage	Support DC 12V Input
Other Functions	Auto power on when there is electricity, Timing boot, Wake on LAN, PXE boot, Watchdog (0～255 level)
Work Temperature	0℃--+50℃ (Commercial HDD), -20℃ -- +50℃ (Industrial SSD), Surface air flow
Work Humidity	5% ～ 95% non-condensing
Certificates	CE, CCC, FCC Class A, ROHS
Dimension	134 x 126 x 38.5 mm
Net Weight	0.7kg

Applications

This rugged and durable industrial mini PC is perfect for harsh environments with its fanless design ensuring minimal noise and dust accumulation. Compact form factor allows easy installation in tight spaces with VESA mounting capability.

Industrial Automation: Controlling machinery and monitoring production lines
Medical: Controlling medical devices and storing patient data
Logistics Transportation: Tracking shipments and managing warehouses
Warehouse: Managing inventory and tracking orders
Electronic Education: Interactive whiteboards and digital signage
